SELECT™ Energy-free glass doors
Energy Door Company’s ProE™ Door is smart-designed to provide optimum performance along with energy consumption savings. Using advanced technology and engineering expertise, ProE offers unparalleled condensation protection even in the most demanding conditions.
With ProE, you get proven durability in an energy-free design, while still providing a wide range of features and options to allow you to merchandise more profitably.
Available Finishes:
Black
Silver Satin
Downloads :
Product Specifications
Door widths
24″, 26″, 28″, 30″
Door height
67", 75", 79"
Shelving widths
24″, 26″, 28″, 30″, 48″, 52″, 56″, 60″
Shelving depths
24″, 27″, 36″, 43″
Optional shelving
Gravity flow
Flex carts
Custom door widths and heights available
Available in Standard White and Black
Our products are compatible with: Hussmann, Kysor Warren, Hillphoenix, Zero Zone, and more.
- Energy-free glass doors for commercial refrigeration
- Medium or low temperature applications
- LED lighting standard
- Field reversible door
- Magnetic door gasket
- High impact metal handle
- Full-length handle available
- High-performance glass
- Continuous or full flange
- 90° hold open
- High humidity protection
- Quick-connect hinge pin
- Self closing
- Torque master tension adjustment
- Dual seal insulated glass
- 10/5/1 Warranty
- Gravity Flow
- Flex Carts
Product comparison
|
Current
SELECT™ Energy-free glass doors
|
PRO-E™ Energy-free glass doors
|
PRIME™ Energy-free glass doors
|
VUE™ Energy-free glass doors
|
SELECT™ Pass-through doors
|
PRO-E™ Pass-through doors
|
|
|---|---|---|---|---|---|---|
| Application | ||||||
| Cooler | ||||||
| Freezer | ||||||
| Heavy-Duty Beer Cave | ||||||
| Temperature/Environment | ||||||
| Normal Temp: 75°F/ 60% RH Ambient/35°F Walk-In | ||||||
| High Humidity: 75°F/ 65% RH Ambient/35°F Walk-In | Optional (65%) | Optional (65%) | ||||
| Low Temp: 75°F/ 55% RH Ambient/ -10°F Walk-In | ||||||
| Low Temp: 75°F/ 60% RH Ambient/ -10°F Walk-In | ||||||
| Glass Pack Configuration | ||||||
| Glass Standard — 3-pane | ||||||
| Glass Standard — 2-pane | ||||||
| Pass-Thru Options | ||||||
| Matching Pass-Thru Door | ||||||
| Optional Glass (1/3 Glass with 2/3 Block out Panel) | ||||||
| Kickplates (10”, 24”, 36”, and 48”) | ||||||
| Energy Consumption* | ||||||
| Normal Temperature - Heated Frame | 1.21 kWh/day | 1.21 kWh/day | 1.21 kWh/day | 1.21 kWh/day | 1.21 kWh/day | 1.21 kWh/day |
| Normal Temperature - French Door - Heated Frame | .79 kWh/day | .79 kWh/day | 79 kWh/day | .79 kWh/day | .79 kWh/day | .79 kWh/day |
| Low Temperature | 3.2 kWh/day | 3.2 kWh/day | 3.2 kWh/day | 3.2 kWh/day |
* Energy consumption values listed are actual values and are based on a catalog size 30” x 75”, 4 door line up for each model.
These doors are designed and certified for use in walk-in cooler and/or walk-in freezer applications.
